A Continuous Thin Film Dryer (TFD) is a high-efficiency industrial drying system engineered for viscous, heat-sensitive, and sticky materials. It enables fast moisture evaporation by forming a thin film layer, ensuring consistent product quality in continuous operation.

A thin film drying system is a continuous thermal process where liquid or semi-solid feed is spread into a uniform thin layer over a heated surface, enabling:

• Instant evaporation
• High heat transfer efficiency
• Controlled drying without degradation

This method is ideal for temperature-sensitive and high-viscosity materials where traditional drying methods fail.

The drying process operates through a precisely controlled sequence:

1. Feed material enters the drying chamber
2. Rotating blades distribute it into a thin film layer
3. Heated jacket transfers thermal energy rapidly
4. Moisture evaporates within seconds
5. Dried product is discharged continuously

This system ensures uniform drying and up to 95% moisture reduction in a short residence time.

• Continuous, uninterrupted production
• High heat transfer efficiency
• Suitable for sticky and viscous materials
• Reduced floor space requirement
• Consistent product quality
• Lower energy consumption
• Minimal thermal damage
• Reduced maintenance requirements

Technical Highlights & Machine Features

Food Processing Applications

• Fruit pulps and concentrates
• Protein and starch extracts
• Dairy-based formulations
• Nutraceutical ingredients

Chemical Processing

• Polymer emulsions and resins
• Industrial pigments and dyes
• Adhesive compounds and gels

Pharmaceutical & Biotech

• Active pharmaceutical ingredients (APIs)
• Botanical and herbal extracts
• Fine and specialty chemicals

Additional Industrial Uses

• Ceramic slurry drying
• Wastewater sludge processing
• Biofuel and biomass derivatives

Complete Turnkey Drying Solutions

 Process design and feasibility analysis

 Pilot testing and validation

 Equipment manufacturing
 Installation and commissioning
 Operator training
 Maintenance and upgrades
